Open CNC Basic Operation Package 2 Operators manual Page 252

Operators manual
3.CUSTOMIZATION B-63924EN/01
- 232 -
action: opbfnc (switching button displays)
<funcs>
:
<funcdef bop2:name="switch_sys" bop2:usage="normal" bop2:onload="true">
<button bop2:type="toggle">
<status>false</status>
<off>
<caption>
<resource>m_main</resource>
<message>MSG_KEY_OPERAT</message>
</caption>
<textstyle>default</textstyle>
<colorref>switching</colorref>
<image />
<action>
<opbfnc>
<confname>func</confname>
<target>sub</target>
<name>import</name>
</opbfnc>
</action>
</off>
<on>
<caption>
<resource>m_main</resource>
<message>MSG_KEY_DISPLAY</message>
</caption>
<textstyle>default</textstyle>
<colorref>switching</colorref>
<image />
<action>
<opbfnc>
<confname>func</confname>
<target>sub</target>
<name>systemmenu</name>
</opbfnc>
</action>
</on>
</button>
</funcdef>
:
</funcs>
