OPEN CNC (Machining Status Monitoring Package) Operators manual Page 13

Operators manual
B-63364EN/03 PREFACE
p - 5
Notation Conventions
The following explains the notation conventions used in this manual:
Menu, command, screen, and worksheet notations
Example Explanation
[File] menu Menu names are enclosed in brackets
[].
[Setting...] Command names are enclosed in
brackets [].
[Log Output Item] Screen Screen names (displayed on the title
bars) are enclosed in brackets [].
[Monitor Information] worksheet Worksheet names (displayed as sheet
titles) are enclosed in brackets [].
<OK> button Command buttons on the screens and
worksheets are enclosed in angle
brackets <>.
Key notations and operation
Example Explanation
[Enter] key Key names are enclosed in brackets [].
[Ctrl]+[Tab] keys When keys are to be pressed and held
down sequentially, the keys are
indicated by connecting them with +,
as shown on the left.
Direction keys The [→], [←], [↑], and [↓] keys are
collectively called the direction keys.
Mouse operations
Example Explanation
Click Pushing and releasing a mouse button
immediately.
Double-click Clicking a mouse button twice in quick
succession.
Drag Moving the mouse while holding down
a mouse button, then releasing the
button at a desired location.
Folders
This manual collectively refers to directories and folders as folders.
