OPEN CNC (Machining Status Monitoring Package) Operators manual Page 42

Operators manual
2. BASIC KNOWLEDGE B-63364EN/03
- 26 -
[Monitor Information] worksheet
This worksheet is used to specify the start and end of monitoring for a CNC
machine. For details of the [Monitor Information] worksheet, see Chapter
6, "MONITORING CNC MACHINES AND OUTPUTTING LOG
DATA."
NOTE
Do not change the name of a worksheet. If the worksheet name
of a worksheet explained above or a log output destination
worksheet is changed, the Machining Status Monitor Package
may not operate correctly. If a worksheet name is changed by
mistake, and the Machining Status Monitor Package cannot
operate correctly, restore the original worksheet name, then
terminate and restart the Machining Status Monitor Package.
