OPEN CNC (Machining Status Monitoring Package) Operators manual Page 96

Operators manual
5. SETTING AND REGISTERING DATA FOR EACH CNC MACHINE B-63364EN/03
- 80 -
2. Item type
Item types prepared in the Machining Status Monitor Package and its
function of the each item type are as follows.
Item type Function
Machine Signal The value of an arbitrary machine signal of the CNC
machine (long type, word type, byte type, and bit type)
is acquired.
Log Output Output worksheet of logging data, output cell position
etc. are specified.
Date Current date is acquired from the personal computer.
Week Current day of the week is acquired from the personal
computer.
Time Current time is acquired from the personal computer.
Calculate
The calculated value is acquired.
Machining Result The machining results (processed part name,
machining process name, and number of processed
parts) are acquired from the data registered in the
machining program information about the program
running in the CNC machine.
O Number(Current) O number of the program which is on execution or
executed last is acquired from the CNC machine.
O Number(Main) O number of the main program which is on execution
or executed last is acquired from the CNC machine.
Sequence Number Sequence number in the program which is on execution
or executed last is acquired from the CNC machine.
Parts Total The total number of processed parts is acquired from
the CNC machine.
Parts Required The required number of parts to be processed is
acquired from the CNC machine.
Parts Count The number of processed parts is acquired from the
CNC machine.
Power On
The power on time is acquired from the CNC machine.
Operating Time
The operating time is acquired from the CNC
machine.
Cutting Time
The cutting time is acquired from the CNC
machine.
Free Purpose The free purpose time is acquired from the CNC
machine.
Cycle Time The cycle time is acquired from the CNC machine.
