OPEN CNC (Machining Status Monitoring Package) Operators manual Page 44

Operators manual
3. REGISTERING CNC MACHINES TO BE MONITORED AND DELETING REGISTERED CNC MACHINES B-63364EN/03
- 28 -
3.1 REGISTERING CNC MACHINES TO BE MONITORED AND
DELETING REGISTERED CNC MACHINES (HSSB VERSION)
This section describes the information related to registering CNC machines and
deleting registered CNC machines about the HSSB version of the Machining
Status Monitor Package.
As for the Ethernet version, see Section 3.2, "REGISTERING CNC
MACHINES TO BE MONITORED AND DELETING REGISTERED
CNC MACHINES (ETHERNET VERSION)".
3.1.1 Registering CNC Machines to Be Monitored and Deleting
Registered CNC Machines
Procedure
1. Select the [CNC Machine Registration] worksheet.
The [CNC Machine Registration] worksheet appears.
NOTE
CNC machines can be registered, and registered CNC machines can be
deleted, only when the monitoring of all CNC machines is stopped.
During the monitoring of a CNC machine, the message shown below
appears on the worksheet. At this time, never modify the value selected
in the monitor combo box, nor the cell values of the worksheet.
