5. SETTING AND REGISTERING DATA FOR EACH CNC MACHINE B-63364EN/03
- 144 -
5.3.1 Machining Program Information
In the Machining Status Monitor Package, it is possible to output the name of
processed part, the machining process name, and the number of processed parts
as the logging data by registering the following data beforehand.
The relation between the main program number of the CNC machine and
the name of the processed part by the main program, the machining process
name, the number of the processed parts.
The monitoring item which acquires the data of "Machining Results" at the
program termination.
The logging output item which outputs processed part name, the machining
process name, and the number of processed parts at the program
termination.
Information for the program to be executed and the part to be machined by the
main program is referred to as "machining program information."
For an explanation of registering monitor items and log output items, see
Section 5.2, "REGISTERING TARGET ITEMS FOR MONITORING AND
LOG DATA OUTPUT" and Appendix B, "EXAMPLES OF REGISTERING
MONITOR ITEMS AND LOG OUTPUT ITEMS."
Explanation
Machining program information
Register the running main program number and the information of the
processed part by that main program into the one line of the worksheet.
The monitoring item or the logging output item consists of the multiple
elements, which are called "Member".
NOTE
The Machining Status Monitor Package has the logging output items
which outputs the machining results logging data as the default
monitoring items and logging output items. So, you can output the
logging data of machining results by registering the machining program
information data.
However, by the default setting, the logging data of machining results is
output by the termination of the main program whether the success or
the failure of the processing.
For an explanation of the default monitor items and log output items, see
Appendix 2, "EXAMPLES OF REGISTERING MONITOR ITEMS AND
LOG OUTPUT ITEMS."
