OPEN CNC (Machining Status Monitoring Package) Operators manual Page 18

Operators manual
1. SETUP B-63364EN/03
- 2 -
1.1 SET UP (HSSB VERSION)
This section describes the information related to the setup of the HSSB version
of the Machining Status Monitor Package.
See Section 1.2, "SET UP (ETHERNET VERSION)," for the explanations
about the setup of the Ethernet version of the Machining Status Monitor
Package.
1.1.1 Environment
The execution environment of the Machining Status Monitor Package is shown
below.
♦Personal computer
A personal computer connected with the High Speed Serial Bus (HSSB)
type 2
FS160i/180i/210i with PC function
Intelligent Terminal type 2, Intelligent Terminal 3.
The necessary environment for execution is as follows:
In case of Windows 95
• 75MHz Pentium or higher processor
• 16MB memory or more
In case of Windows NT 4.0
• 120MHz Pentium or higher processor
• 32MB memory or more
In case of Windows 2000 Professional
• 166MHz Pentium or higher processor
• 48MB memory or more
The commendable environment for execution is as follows:
In case of Windows 95
• 120MHz Pentium or higher processor
• 32MB memory or more
In case of Windows NT 4.0
• 150MHz Pentium or higher processor
• 64MB memory or more
