OPEN CNC (Machining Status Monitoring Package) Operators manual Page 162

Operators manual
5. SETTING AND REGISTERING DATA FOR EACH CNC MACHINE B-63364EN/03
- 146 -
The following registered data is handled as described below:
• The main program number is invalid (for example, 0 or less, blank, or
a non-numeric value)
The machining program information is ignored.
• The number of processed parts is invalid (for example, blank or non-
numeric value)
The number of processed parts is assumed to be 0.
NOTE
When many rows of machining program information are registered,
the amount of memory that corresponds to the registered information
is consumed when the monitor is executed and log data is output.
It is recommended that machining program information be deleted as
soon as it is no longer necessary.
For an explanation of deleting machining program information, see
Section 5.3.3, "Deleting Rows from Machining Program Information."
A row on which all the members of the machining program information
are blank is regarded as being the last row. Thus, any machining
program information registered after a blank row is ignored.
