OPEN CNC (Machining Status Monitoring Package) Operators manual Page 173

Operators manual
B-63364EN/03 6. MONITORING CNC MACHINES AND OUTPUTTING LOG DATA
- 157 -
6.3 STOPPING THE MONITORING OF CNC MACHINES
In order to terminate the monitoring the CNC machines, there are two methods
as follows.
From the Machining Status Monitor Package
Terminate the monitoring the CNC machines by selecting the items of the
[Monitor] menu bar, or monitoring combo-box of the [Monitor
Information] worksheet of the Machining Status Monitor Package.
For an explanation of how to stop the monitoring of CNC machines from
the Machining Status Monitor Package, see Section 6.3.1, "Stopping the
Monitoring of CNC Machines from the Machining Status Monitor
Package."
From logging data output file
Terminate the monitoring the CNC machines by selecting the items of the
[Monitor] menu bar of the logging data output file.
For an explanation of how to stop CNC machines from the log data output
file, see Section 6.3.2, "Stopping the Monitoring of CNC Machines from
the Log Data Output File."
