OPEN CNC (Machining Status Monitoring Package) Operators manual Page 97

Operators manual
B-63364EN/03 5. SETTING AND REGISTERING DATA FOR EACH CNC MACHINE
- 81 -
The item types are divided into the following groups.
Monitoring item
All item types except "Log Output"
Logging output item
"Log output"
NOTE
When in the DNC operation mode, the correct main program number
cannot be acquired at item type "O Number(Main)".
In case of the following item types, the Machining Status Monitor
Package cannot acquired the correct monitoring data unless the CNC
machine has the proper options and ladder program.
• Item type
Parts Total, Parts Required, Parts Count, Power On, Operating
Time, Cutting Time, Free Purpose, Cycle Time
• Necessary options and ladder program
Options
Machining Time, Parts Count
Ladder program
Ladder program to count the total number of the processed parts
and the number of the processed parts.
