OPEN CNC (Machining Status Monitoring Package) Operators manual Page 180

Operators manual
6. MONITORING CNC MACHINES AND OUTPUTTING LOG DATA B-63364EN/03
- 164 -
NOTE
Error occurrence information is usually output to the error occurrence
information output sheet of the log data output file. If error occurrence
information cannot be output to the log data output file (such as when the
log data output file cannot be created), however, it is output to the error
occurrence information output sheet of the Machining Status Monitor
Package.
The name of the error occurrence information output sheet of the Machining
Status Monitor Package is "Common Error Output Sheet."
Error occurrence information is added to the error occurrence information
output sheet and stored on the sheet. Storing error occurrence information
consumes memory area. therefore, regularly deleting unnecessary error
occurrence information is recommended. Deleting error occurrence
information during the monitoring of CNC machines is not effective
because the next error occurrence information is output following the last
line before deletion. Open the log data output file using a program such as
MS Excel independently of the Machining Status Monitor Package and
delete the error occurrence information. The user normally need not delete
the error occurrence information of the error occurrence information output
sheet (worksheet name: "Common Error Output Sheet") of the Machining
Status Monitor Package because the information is output from the first row
again each time the monitoring CNC machines starts. Stop the monitoring
of all CNC machines before deleting the error occurrence information.
In the Ethernet version, some error logs are outputted in [Common Error
Output Sheet] worksheet when a monitoring is started.
