OPEN CNC (Machining Status Monitoring Package) Operators manual Page 95

Operators manual
B-63364EN/03 5. SETTING AND REGISTERING DATA FOR EACH CNC MACHINE
- 79 -
Member name Description
I/O type In case of the monitoring item,
Shows the type of acquiring monitoring data(acquire the
current or acquire the differential value).
In case of the logging output item,
Shows the type of outputting the logging data(overwrite
output or additional output).
Real value In case of the monitoring item,
Shows the area where the raw data from the CNC machine or
the personal computer is stored.
In case of the logging output item,
This member does not exist.
Output value In case of the monitoring item,
Shows the conversion formula which converts the data stored
at "Real value" to the output value.
In case of the logging output item,
Shows the calculation formula which specifies the position of
the monitoring item where the logging data is acquired.
Address In case of the monitoring item,
Item type: Machine Signal
Shows the address of the acquired machine signal.
Item type: Machining Results
Shows the area where the processed part name acquired
from the machining results is stored.
In case of the logging output item,
Shows the destination cell for the logging data.
Data type In case of the monitoring item,
Item type: Machine Signal
Shows the data type of the acquired machine signal (long
type, word type, byte type, and bit type).
Item type: Machining Results
Shows the area where the machining process name
acquired from the machining results is stored.
In case of the logging output item,
This member does not exist.
Refer to "3. Item type and member’s content" in this paragraph for each
member’s detail.
