OPEN CNC (Machining Status Monitoring Package) Operators manual Page 3

Operators manual
s - 1
This manual includes safety precautions for protecting the user and preventing damage to
the machine. Precautions are classified into Warnings and Cautions according to their
bearing on safety. Also, supplementary information is described as Notes. Read the
Warnings, Cautions, and Notes thoroughly before attempting to use the machine.
Read this manual carefully, and store it in a safe place.
SAFETY PRECAUTIONS
WARNING
Applied when there is a danger of the user being injured or when there
is a danger of both the user being injured and the equipment being
damaged if the approved procedure is not observed.
CAUTION
Applied when there is a danger of the equipment being damaged, if the
approved procedure is not observed.
NOTE
Notes is used to indicate supplementary information other than
Warnings and Cautions.
