OPEN CNC (Machining Status Monitoring Package) Operators manual Page 26

Operators manual
1. SETUP B-63364EN/03
- 10 -
1.2.2 Installing the Machining Status Monitor Package
Procedure
1. Insert the disk (A02B-0207-K782#EN07-1) into the floppy disk drive.
2. Click the Windows [Start] button.
3. Select [Run…].
4. Enter <drive-name>:SETUP, then click the <OK> button. (<drive-
name> is the name of the 3.5-inch floppy disk drive.)
5. Perform installation by following the prompts displayed on the screen.
NOTE
The Machining Status Monitor Package is realized using socket
communication (TCP/IP communication) with the FANUC Ethernet
board. Before starting to use this function, check the following items by
referencing the FANUC Ethernet Board Operator’s Manual (B-
63354EN).
• TCP/IP setting at the personal computer
• Setting of the FANUC Ethernet board and FOCAS1
(DNC1)/Ethernet function at the CNC
• Network connection between the personal computer and the CNC
