3. REGISTERING CNC MACHINES TO BE MONITORED AND DELETING REGISTERED CNC MACHINES B-63364EN/03
- 30 -
3.1.2 Registering CNC Machines to Be Monitored
CNC machines to be monitored are automatically registered according to the
setting of the driver for the High Speed Serial Bus when the Machining Status
Monitor Package is started. When registering an additional CNC machine to be
monitored, terminate the Machining Status Monitor Package, then change the
setting of the driver for the High Speed Serial Bus.
When the Machining Status Monitor Package is started, the CNC machine
registration status is as follows:
When the Machining Status Monitor Package is started for the first time
after being installed
The node names of those CNC machines that are managed by the driver of
the High Speed Serial Bus are automatically recognized. The node names
are used as the CNC machine names in the Machining Status Monitor
Package. Those CNC machines are automatically registered as the CNC
NOTE
The [CNC Machine Registration] worksheet cannot be used to add,
modify or delete those CNC machines that are managed by the driver
of the High Speed Serial Bus. Set the driver of the High Speed Serial
Bus to add, modify, or delete CNC machines. For an explanation of
how to set the driver of the High Speed Serial Bus, refer to one of the
followings.
- Release note (README.TXT) on the driver library floppy disk
(A02B-0207-K730#ZZ07-1).
- Release note (README.TXT) on the drivers disk (A02B-0207-
K791#ZZ07-1).
- Release note (README.TXT) on the drivers disk (A02B-0207-
K792#ZZ07-1).
- Release note (README.TXT) on the drivers disk (A02B-0207-
K793#ZZ07-1).
When setting the driver of the High Speed Serial Bus, use the following
conventions to assign node names to CNC machines:
• A unique node name must be assigned to each CNC machine.
• The following characters cannot be used:
/ : \ [ ] * ? , ; " < > |
If a specified node name does not satisfy the above conventions, the
CNC machine name in the Machining Status Monitor Package will be
"NC-*" (*: Serial number).
