OPEN CNC (Machining Status Monitoring Package) Operators manual Page 24

Operators manual
1. SETUP B-63364EN/03
- 8 -
1.2 SET UP (ETHERNET VERSION)
This section describes the information related to the setup of the Ethernet
version of the Machining Status Monitor Package.
See Section 1.1, "SET UP (HSSB VERSION)," for the explanations about
the setup of the HSSB version of the Machining Status Monitor Package.
1.2.1 Environment
The execution environment of the Machining Status Monitor Package is shown
below.
♦Personal computer
A personal computer connected to FS16i/18i/21i/15i via the Ethernet.
The necessary environment for execution is as follows:
In case of Windows 95
• 120MHz Pentium or higher processor
• 32MB memory or more
In case of Windows NT 4.0
• 166MHz Pentium or higher processor
• 48MB memory or more
In case of Windows 2000 Professional
• 166MHz Pentium or higher processor
• 48MB memory or more
The commendable environment for execution is as follows:
In case of Windows 95
• 166MHz Pentium or higher processor
• 48MB memory or more
In case of Windows NT 4.0
• 200MHz Pentium II or higher processor
• 64MB memory or more
In case of Windows 2000 Professional
• 333MHz Pentium II or higher processor
• 128MB memory or more
