B-63364EN/03 B. EXAMPLES OF REGISTERING MONITOR ITEMS AND LOG OUTPUT ITEMS
- 171 -
B
This appendix explains registered data by using the following examples of
registering monitor items and log output items:
1) Default monitor and log output items of the Machining Status Monitor
Package
2) Log data output of number and used time of each tool used in the program
For details of the monitor and log output item data, see Section 5.2.1, "Monitor
and Log Output Items."
For an explanation of the registration of the monitor and log output item data,
see Section 5.2.2, "Examples of Registering and Changing Monitor Items and
Log Output Items."
1) Default monitor and log output items of the Machining Status Monitor
Package
The following log data items are output as the default monitor and log
output items:
O number and sequence numbers of the program being executed
Main program operation data (start date and time, end date and time,
main program number, execution time, cutting time, and noncutting
time)
Data related to machining according to the main program (end date
and time, processed part name, machining process name, processed
part count, and main program number)
EXAMPLES OF REGISTERING MONITOR
ITEMS AND LOG OUTPUT ITEMS
