2. BASIC KNOWLEDGE B-63364EN/03
- 24 -
2.4 OPERATION FLOW AND WORKSHEET OUTLINE
This section explains the operation flow from the customization of the
Machining Status Monitor Package to the acquisition of specific monitor data
to log data output. The section also outlines the worksheet used for each
operation step. Before customizing the Machining Status Monitor Package,
stop the monitoring operation.
Flow of operation and worksheet to be handled
<1>Registration and deletion of CNC machines to be monitored
Register the CNC machines to be monitored to the Machining Status
Monitor Package, or delete the CNC machine which has been registered.
• Worksheet name
CNC machine registration
<2>Setting concerning whole of machining status monitor package
Set the parameters concerning whole of the Machining Status Monitor
Package, such as output format of the logging data file.
• Worksheet name
Parameter (Common)
<3>Setting and registration of the data of each CNC machine.
Set and register the parameters, monitoring items, output items as the
logging data, to each CNC machine.
<3>-1 Setting of parameters of each CNC machine
• Worksheet name
Parameter(********)
<3>-2 Registration of monitoring items and output items as the logging
data.
• Worksheet name
Monitor,Log(********)
<3>-3 Registration of machining program information.
• Worksheet name
Program(********)
Each worksheet exists for each CNC machine and each CNC
machine name is set in "********" of the above-mentioned
worksheet name. You can set and register the data for each CNC
machine when that CNC machine is not monitored even if other
CNC machines are monitored.
