Series 16i/160i/160is/18i/180i/180is - Model B Parameter manual Page 105

Parameter manual

Page of 782

/ 782

B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 93 -

Maximum allowable feedrate for the feedrate check function for each axis

1436

[Data type] 2-word axis

[Unit of data, valid data range]

Valid data range

Input increment Unit of data

IS-A, IS-B IS-C

Metric machine 1 mm/min 0, 30 to 240000 0, 6 to 100000

Inch machine 0.1 inch/min 0, 30 to 96000 0, 6 to 48000

Rotary axis 1 deg/min 0, 30 to 240000 0, 6 to 100000

This function is invalid when this parameter is set to 0.

Set a maximum allowable feedrate for each axis. If the value set in this

parameter is exceeded, a decelerated stop occurs with P/S alarm No.

5323 ("Excessive Feedrate").

The deceleration check function checks data obtained by converting

the setting of this parameter to a travel distance moved every 8 msec.

1440 External deceleration rate 2 of cutting feed

[Data type] Word

[Unit of data, valid data range]

Valid data range

Input increment Unit of data

IS-A, IS-B IS-C

Metric machine 1 mm/min 6 to 15000 6 to 12000

Inch machine 0.1 inch/min 6 to 6000 6 to 4800

Set the external deceleration rate of cutting feed.

1441 External deceleration rate 2 of rapid traverse for each axis

[Data type] Word axis

[Unit of data, valid data range]

Valid data range

Input increment Unit of data

IS-A, IS-B IS-C

Metric machine 1 mm/min 6 to 15000 6 to 12000

Inch machine 0.1 inch/min 6 to 6000 6 to 4800

Rotary axis 1 deg/min 6 to 15000 6 to 12000

Set the external deceleration rate of rapid traverse for each axis.
