B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 657 -

#7 #6 #5 #4 #3 #2 #1 #0

13112 NTD NTA DAP SPI SVI IDW

[Data type] Bit

IDW Editing on the servo information screen or spindle information screen

0 : Prohibited.

1 : Not prohibited.

SVI Servo information screen is

0 : Displayed.

1 : Not displayed.

SPI Spindle information screen is

0 : Displayed.

1 : Not displayed.

DAP In the advanced preview control mode, "APC" blinking display is:

0 : Not provided.

1 : Provided.

NTA On the manual feed screen for 5-axis machining, the table reference

travel distance is:

0 : Displayed.

1 : Not displayed.

NTD On the manual feed screen for 5-axis machining, the tool axis

reference travel distance is:

0 : Displayed.

1 : Not displayed.

13130 Path display order on the screen that displays multiple paths simultaneously

[Data type] Byte

[Valid data range] 0 to 5

This parameter sets the order of path display on the screen that

displays multiple paths simultaneously when two-path or three-path

control (T series only) is used.

The table below indicates the relationships between settings and

display orders.

System Setting Order

0 1st path, 2nd path

2-path

1 2nd path, 1st path

0 1st path, 2nd path, 3rd path

1 2nd path, 1st path, 3rd path

2 1st path, 3rd path, 2nd path

3 3rd path, 1st path, 2nd path

4 2nd path, 3rd path, 1st path

3-path

(T series only)

5 3rd path, 2nd path, 1st path
