B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 303 -

#7 #6 #5 #4 #3 #2 #1 #0

SYW SYR

4802

[Data type] Bit

SYR In spindle synchronous control by CNC program, the value of address

R is:

0 : Phase shift amount of the slave spindle.

1 : Phase shift amount of the master spindle.

SYW The block immediately after spindle synchronous control G51.8 by

CNC program is:

0 : Executed immediately when PSYFN signal <G348#0> is set to 1.

1 : Executed after completion of spindle synchronous control or

spindle phase synchronous control.

4810

Error pulse between two spindles when synchronizing phases in the serial

spindle synchronous control mode

[Data type] Byte

[Unit of data] Pulse

[Valid data range] 0 to 255

Set the difference in error pulses between two spindles when

synchronizing phases in the serial spindle synchronous control mode.

When the difference in error pulse between two spindles is within the

value set in this parameter, the spindle phase synchronous control

completion signal FSPPH becomes "1".

This parameter is used to check the difference in phase in synchronous

control and to confirm the completion of synchronous control in the

serial spindle synchronous control mode.

Serial spindle parameters such as parameter No. 4032 also need to be

set to spindle synchronous control.
