4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 606 -

8580

Maximum value of the operation range of the first high-speed position switch

or position where the first high-speed position switch is turned on

8581

Maximum value of the operation range of the second high-speed position

switch or position where the second high-speed position switch is turned on

8582

Maximum value of the operation range of the third high-speed position

switch or position where the third t high-speed position switch is turned on

8583

Maximum value of the operation range of the fourth high-speed position

switch or position where the fourth high-speed position switch is turned on

8584

Maximum value of the operation range of the fifth high-speed position switch

or position where the fifth high-speed position switch is turned on

8585

Maximum value of the operation range of the sixth high-speed position

switch or position where the sixth high-speed position switch is turned on

8586

Maximum value of the operation range of the seventh high-speed position switch

or position where the seventh high-speed position switch is turned on

8587

Maximum value of the operation range of the eighth high-speed position

switch or position where the eighth high-speed position switch is turned on

8588

Maximum value of the operation range of the ninth high-speed position

switch or position where the ninth high-speed position switch is turned on

8589

Maximum value of the operation range of the tenth high-speed position

switch or position where the tenth high-speed position switch is turned on

[Data type] 2-word

[Unit of data]

Input increment IS-A IS-B IS-C Unit

Metric machine 0.01 0.001 0.0001 mm

Inch machine 0.001 0.0001 0.00001 inch

Rotary axis 0.01 0.001 0.0001 deg

[Valid data range] -99999999 to 99999999

Set the following value, depending on the output method of the

high-speed position switch:

• For normal type

Maximum value of the operation range of the first to tenth

high-speed position switches

• For direction-dependent type

Position where the first to tenth position switches are turned on

NOTE

For each high-speed position switch, an output

method can be selected using bit 0 (HM1) of

parameter No. 8508 to bit 7 (HMG) of parameter

No. 8509.

When direction-dependent type is selected, set a

direction for turning on each high-speed position

switch in bit 0 (HA1) of parameter No. 8512 to bit 7

(HAG) of parameter No. 8513.
