B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 725 -

19581

Tolerance specification for nano smoothing

[Data type] 2-word

[Unit of data]

Increment system IS-B IS-C Unit

Metric machine 0.001 0.0001 mm

Inch machine 0.0001 0.00001 inch

[Valid data range] 0 to 99999999

This parameter sets a tolerance for a program created by very small

line segments for nano smoothing. If 0 is set in this parameter, the

least travel distance in the setting unit is assumed as a tolerance. A

curved figure is estimated within the tolerance range.

19582

Minimum travel distance of a block that makes a decision based on an angle

difference between nano smoothing blocks

[Data type] 2-word

[Unit of data]

Increment system IS-B IS-C Unit

Metric machine 0.001 0.0001 mm

Inch machine 0.0001 0.00001 inch

[Valid data range] 0 to 99999999

This parameter sets the minimum travel distance of a block that makes

a decision based on an angle difference between nano smoothing

blocks. If a value less than the setting of this parameter is set for a

block, a decision based on an angle difference is not made in the

block.

If 0 is set in this parameter, a decision based on an angle difference is

made in all blocks.

In this parameter, a value greater than the setting of parameter No.

8490 for specifying the minimum travel distance of a block where

nano smoothing is applied needs to be set.
