B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 685 -

NOTE

2 If an axis for which dual check safety is disabled by

setting bit 6 (DCNx) of parameter No. 1904 to 1 is

specified, the safe position switch signal of the

corresponding number is not output.

3 With all tool posts except tool post 2 in 1-CPU

2-path control or tool post 3 in 2-CPU 3-path

control, the 9th to 32nd safe position switches are

valid only when the FSSB I/O module (for

extension) is used. When the FSSB I/O module (for

extension) is not used, set 0 in parameters No.

13888 to No. 13911. If a setting is made to use the

9th to 32nd safe position switches when the FSSB

I/O module (for extension) is not used, servo alarm

No. 493 is issued at power-on time.

With tool post 2 in 1-CPU 2-path control or tool

post 3 in 2-CPU 3-path control, safe position

switches are valid only when the FSSB I/O module

for extension is used for connection to tool post 1

(in 1-CPU 2-path control) or tool post 2 (in 2-CPU

3-path control).

When the FSSB I/O module (for extension) is not

used, set 0 in parameters No. 13880 to No. 13911.

If a setting is made to use safe position switches

when the FSSB I/O module (for extension) is not

used, servo alarm No. 493 is issued at power-on

time.

4 Parameters No. 13880 to No. 13911 are safety

parameters, so that these parameters are

protected by a key and password for dual check

safety. When modifying a parameter, set the safety

parameter password in parameter No. 3226 (safety

parameter key).

5 When parameters No. 13880 to No. 13911 are set,

the power must be turned off before operation is

continued.

13920 Maximum operation range of the 1st safe position switch

13921 Maximum operation range of the 2nd safe position switch

13922 Maximum operation range of the 3rd safe position switch

13923 Maximum operation range of the 4th safe position switch

13924 Maximum operation range of the 5th safe position switch

13925 Maximum operation range of the 6th safe position switch

13926 Maximum operation range of the 7th safe position switch

13927 Maximum operation range of the 8th safe position switch
