B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 431 -

#7 #6 #5 #4 #3 #2 #1 #0

6202 1S8 1S7 1S6 1S5 1S4 1S3 1S2 1S1

#7 #6 #5 #4 #3 #2 #1 #0

6203 2S8 2S7 2S6 2S5 2S4 2S3 2S2 2S1

#7 #6 #5 #4 #3 #2 #1 #0

6204 3S8 3S7 3S6 3S5 3S4 3S3 3S2 3S1

#7 #6 #5 #4 #3 #2 #1 #0

6205 4S8 4S7 4S6 4S5 4S4 4S3 4S2 4S1

#7 #6 #5 #4 #3 #2 #1 #0

6206 DS8 DS7 DS6 DS5 DS4 DS3 DS2 DS1

[Data type] Bit

1S1 to 1S8 Specify which high-speed skip signal is enabled when the G31 skip

command is issued. The bits correspond to the following signals:

1S1 HDI0

1S2 HDI1

1S3 HDI2

1S4 HDI3

1S5 HDI4

1S6 HDI5

1S7 HDI6

1S8 HDI7

1S1 to 1S8, 2S1 to 2S8, 3S1 to 3S8, 4S1 to 4S8, DS1 to DS8

Specify which skip signal is enabled when the skip command (G31, or

G31P1 to G31P4) and the dwell command (G04, G04Q1 to G04Q4)

are issued with the multi-step skip function.

The following table shows the correspondence between the bits, input

signals, and commands.

The setting of the bits have the following meaning :

0 : The skip signal corresponding to the bit is disabled.

1 : The skip signal corresponding to the bit is enabled.

High-speed skip function Multi-step skip function

Command

Input signal

G31

Command

Input signal

G31

G31P1

G04Q1

G31P2

G04Q2

G31P2

G04Q2

G31P4

G04Q4

G04

HDI0 1S1 SKIP/HDI0 1S1 2S1 3S1 4S1 DS1

HDI1 1S2 SKIP2/HDI1 1S2 2S2 3S2 4S2 DS2

HDI2 1S3 SKIP3/HDI2 1S3 2S3 3S3 4S3 DS3

HDI3 1S4 SKIP4/HDI3 1S4 2S4 3S4 4S4 DS4

HDI4 1S5 SKIP5/HDI4 1S5 2S5 3S5 4S5 DS5

HDI5 1S6 SKIP6/HDI5 1S6 2S6 3S6 4S6 DS6

HDI6 1S7 SKIP7/HDI6 1S7 2S7 3S7 4S7 DS7

HDI7 1S8 SKIP8/HDI7 1S8 2S8 3S8 4S8 DS8

NOTE

HDI0 to HDI7 are high-speed skip signals.
