B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 199 -

DAC Absolute position

0 : The actual position displayed takes into account cutter

compensation (M series) or tool nose radius compensation (T

series).

1 : The programmed position displayed does not take into account

cutter compensation (M series) or tool nose radius compensation

(T series).

NOTE

Be sure to set this parameter to 0 when bit 6 (DAK)

of parameter No. 3106 is set to 1.

#7 #6 #5 #4 #3 #2 #1 #0

DPS PCF DPF

3105

SMF DPS PCF DPF

[Data type] Bit

DPF Display of the actual speed on the current position display screen,

program check screen and program screen (MD1 operation)

0 : Not displayed

1 : Displayed

PCF Addition of the movement of the PMC-controlled axes to the actual

speed display

0 : Added

1 : Not added

NOTE

For each setting, movement along any axis other

than those controlled by the CNC (see the

description of parameter No. 1010) is not reflected

in the actual speed display.

DPS Actual spindle speed and T code

0 : Not always displayed

1 : Always displayed

NOTE

For the M series, the threading and synchronous

feed option is required to display the actual spindle

speed.

SMF During simple synchronous control, movement along a slave axis is:

(see the parameter No.8311)

0 : Included in the actual speed display

1 : Not included in the actual speed display
