4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 52 -

#7 #6 #5 #4 #3 #2 #1 #0

1012 IDGx

[Data type] Bit axis

IDGx The function for setting the reference position again, without dogs, is:

0 : Not inhibited.

1 : Inhibited.

NOTE

1 IDGx is enabled when bit 7 (IDG) of parameter

No.1002 is set to 1.

2 When the function for setting the reference

position, without dogs, is used, and the reference

position is lost for some reason, an alarm

requesting reference position return (No.300) is

generated when the power is next turned on. If the

operator performs reference position return, as a

result of mistakenly identifying the alarm as that

requesting the operator to perform a normal

reference position return, an invalid reference

position may be set. To prevent such an operator

error, bit 0 (IDGx) of parameter No.1012 is

provided to prevent the reference position from

being set again without dogs.

(1) If bit 7 (IDG) of parameter No.1002 is set to 1,

bit 0 (IDGx) of parameter No.1012 is

automatically set to 1 when the reference

position is set using the function for setting the

reference position without dogs. This prevents

the reference position from being set again

without dogs.

(2) Once the reference position is prevented from

being set for an axis again, without dogs, any

attempt to set the reference position for the

axis without dogs results in the output of an

alarm (No.090).

(3) When the reference position must be set again

without dogs, set IDGx to 0 before setting the

reference position.

#7 #6 #5 #4 #3 #2 #1 #0

DWT WIC SVS ZRL RHR

1015

DWT WIC ZRL RHR

[Data type] Bit

RHR After increment system (inch/metric) switching, for the rotary axis, the

first G28 command causes reference position return:

0 : At a low speed.

1 : At a high speed/
