B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 321 -

3OF If the commands of three-dimensional coordinate conversion and tool

length compensation are not nested, an alarm is:

0 : Not raised.

1 : Raised. (P/S049 alarm)

[Example 1] An alarm is raised in the following cases:

<1> G68 X__ Y__ Z__ I0 J1 K0 R50.;

G43 H1 ;

G69 ;

G49 ;

<2> G43 H1 ;

G68 X__ Y__ Z__ I0 J1 K0 R50.;

G49 (or G43 H2, etc.);

G69 ;

←

P/S049 raised

←

P/S049 raised

[Example 2] No alarm is raised in the following cases:

<3> G68 X__ Y__ Z__ I0 J1 K0 R50.;

G43 H1 ;

G49 ;

G69 ;

<4> G43 H1 ;

G68 X__ Y__ Z__ I0 J1 K0 R50.;

G69 ;

G49 ;

NOTE

To program as in <4> of [Example 2] above, set

both bit 2 (D3R) of parameter No. 5400 and bit 6

(LVK) of parameter No. 5003 to 1, so that

three-dimensional coordinate conversion and tool

length compensation are not cancelled by a reset.

(If a reset is made in the middle of a program, the

direction of tool length compensation will be

affected.)

As shown below, a command to cancel tool length

compensation (G28, etc.) will not cause an alarm to

be raised. If a command like this is specified in the

G68 mode, program as indicated in <3> above.

G43 H1 ;

G68 X__ Y__ Z__ I0 J1 K0 R50.;

G28 X__ Y__ Z__ ;

G69 ;

←

Offset is cancelled.

No alarm is raised.
