4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 434 -

#7 #6 #5 #4 #3 #2 #1 #0

6215 CSTx

[Data type] Bit axis

CSTx For the Cs contour controlled axis, the torque limit skip function is:

0 : Disabled.

1 : Enabled.

Torque limit skip operation is performed for the Cs counter controlled

axis by using the serial spindle torque limit command signal

TLMH<G070, G074, G204, G266> and the load detection signal

LDT1<F045, F049, F196, F266>.

NOTE

When this parameter is set to perform torque limit skip

operation for a Cs counter controlled axis, note the

following:

1 For the Cs contour controlled axis (spindle) that

uses the torque limit skip function, set bit 4 of serial

spindle parameter No. 4009 to 1 so that load

detection signals are output even during

acceleration/deceleration.

2 If the disturbance torque detection state (LDT1 = 1)

is set when the torque limit command is specified

(TLMH1 = 1) in the Cs mode, no excessive error

check at stop is performed for the axis.

3 If the disturbance torque detection state (LDT1 = 1)

is set in the Cs mode, no in-position check is made

for the axis.

6220

Period during which input is ignored for continuous high-speed skip signal

[Data type] Byte

[Unit of data] 8 msec

[Valid data range] 3 to 127 (× 8 msec)

This parameter specifies the period that must elapse between a

high-speed skip signal being input and input of the next high-speed

skip signal being enabled, for the continuous high-speed skip function.

This parameter is used to ignore chattering in skip signals.

NOTE

If a value that falls outside the range is specified, 3

(24 msec) is assumed.
