B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 549 -

MCEx In automatic workpiece coordinate system setting, performed when

composite control is canceled:

0 : A workpiece coordinate system is automatically set in the same

way as normal.

1 : The coordinate system of the other path subject to axis

recomposition is used.

NOTE

MCEx is enabled when (bit 5 (MPSx) of parameter

No.8162) is set to 1.

SPNx The workpiece coordinate and relative coordinate of a slave axis

subject to synchronous control is:

0 : Updated.

1 : Not updated.

OPSx When superimposed control is canceled, control in which an amount

of movement along a master axis subject to superimposed control is

added to the workpiece coordinate of a slave axis is:

0 : Not applied.

1 : Applied.

SOKx If a master axis subject to superimposed control is also subject to

synchronous control:

0 : An alarm is issued when superimposed control is started during

synchronous control.

1 : No alarm is issued when superimposed control is started during

synchronous control.

NOTE

1 MWSx and MWEx are mutually exclusive, so that

only one of these parameters must be selected.

Similarly, MCSx and MCEx are mutually exclusive,

so that only one of these parameters must be

selected.

2 Specify these parameters for the axis of each path

subject to each control function.

#7 #6 #5 #4 #3 #2 #1 #0

SMT NA0 CPM SVF SIC

8165

SVF

NOTE

When at least one of these parameters is set, the

power must be turned off before operation is

continued.

[Data type] Bit

SIC One-path superimposed control is:

0 : Disabled.

1 : Enabled.
