B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 485 -

7120

Axis configuration in tool direction handle feed and normal tool direction

handle feed

[Data type] Byte

[Valid data range] 1 to 4

Let A, B, and C be the rotary axes for the basic three axes X, Y, and Z

in the basic coordinate system in tool direction handle feed and

normal tool direction handle feed. If the tool direction is the Z-axis

when the tool on the rotary axes is at the machine zero point, the four

types below are considered according to the machine axis

configuration. For a 4-axis machine, types (1) and (2) are available.

(1) A-C axis type

(2) B-C axis type

(3) A-B axis (A-axis master) type

(4) A-B axis (B-axis master) type

This parameter selects a type. Values of 1 to 4 are assigned to these

types (when bit 0 (TLX) of parameter No. 7104 is set to 1), in order,

from top to bottom. When the X-axis represents the tool direction, the

above types are changed to B-A axis type, C-A axis type, B-C axis

(B-axis master) type, and B-C axis (C-axis master) type.

7121

Axis selection in tool direction handle feed mode

[Data type] Byte

[Valid data range] 1 to number of controlled axes

This parameter sets an axis number for the manual handle feed axis

selection signal for the first manual pulse generator to enable tool

direction handle feed mode. When the value set in this parameter

matches the value of the manual handle feed axis selection signal, tool

direction handle feed mode is enabled.

7141

Axis selection in the X direction for the normal tool direction handle feed

7142

Axis selection in the Y direction for the normal tool direction handle feed

[Data type] Byte

[Valid data range] 1 to 8

These parameters specify the axis selection signal for the first manual

pulse generator used to enable the normal tool direction handle feed.

When the setting of these parameters matches the manual handle feed

axis selection signal, normal tool direction handle feed mode is

enabled.
