4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 446 -

M code (3) in group E for backward movement by the manual handle retrace function

6429

M code (4) in group E for backward movement by the manual handle retrace function

6430

M code (1) in group F for backward movement by the manual handle retrace function

6431

M code (2) in group F for backward movement by the manual handle retrace function

6432

M code (3) in group F for backward movement by the manual handle retrace function

6433

M code (4) in group F for backward movement by the manual handle retrace function

6434

M code (1) in group G for backward movement by the manual handle retrace function

6435

M code (2) in group G for backward movement by the manual handle retrace function

6436

M code (3) in group G for backward movement by the manual handle retrace function

6437

M code (4) in group G for backward movement by the manual handle retrace function

6438

M code (1) in group H for backward movement by the manual handle retrace function

6439

M code (2) in group H for backward movement by the manual handle retrace function

6440

M code (3) in group H for backward movement by the manual handle retrace function

6441

M code (4) in group H for backward movement by the manual handle retrace function

6442

M code (1) in group I for backward movement by the manual handle retrace function

6443

M code (2) in group I for backward movement by the manual handle retrace function

6444

M code (3) in group I for backward movement by the manual handle retrace function

6445

M code (4) in group I for backward movement by the manual handle retrace function

6446
