4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 158 -

1 Set bit 1 (OPTx) of parameter No. 1815 to 1, bit 2 (DCLx) of

parameter No. 1815 to 1, and bit 3 (DCRx) of parameter No.

1815 to 0/1 to enable an encoder with absolute addressing

reference marks (linear scale/rotary encoder).

Set a proper value in parameter Nos. 1821 and 1882.

Set 0 in parameter No. 1240.

Set 0 in parameter Nos. 1883 and 1884.

2 Establish a reference position at a proper location.

(As the result, the machine coordinate represents the distance

from the encoder origin to the current position.)

3 Position the machine accurately at the reference position by jog

feed or handle feed.

4 In parameter No. 1883, set the machine coordinate (diagnosis

screen No. 301) converted to the detection unit (diagnosis screen

No. 301 multiplied by CMR).

5 Set parameter No. 1240 if necessary.

NOTE

This method cannot be used if the distance from

the encoder origin to the reference position

exceeds 99,999,999.

[Method of setting parameter No. 1883]

(When an encoder with distance-coded reference marks (linear

scale/rotary encoder) (detection circuit C) is used)

A value to be set in parameter No. 1883 can be determined using the

procedure below.

1 Set bit 1 (OPTx) of parameter No. 1815 to 0/1 and bit 2 (DCLx)

of parameter No. 1815 to 1 to enable an encoder with

distance-coded reference marks (linear scale/rotary encoder)

(detection circuit C).

Set 0 in parameter No. 1240.

Set 0 in parameter Nos. 1883 and 1884.

2 Establish a reference position at a proper location.

(As the result, the machine coordinate represents the distance

from the encoder origin to the current position.)

3 Position the machine accurately at the reference position by jog

feed or handle feed.

4 In parameter No. 1883, set the machine coordinate (diagnosis

screen No. 301) converted to the detection unit (diagnosis screen

No. 301 multiplied by CMR).

5 Set parameter No. 1240 if necessary.

NOTE

This method cannot be used if the distance from

the encoder origin to the reference position

exceeds 99,999,999.
