4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 510 -

Steady state confirmation time duration in polygon machining with two

spindles

7632

[Data type] Word

[Unit of data] msec

[Valid data range] 0 to 32767

This parameter sets the duration required to confirm that both spindles

have reached their specified speeds in polygon machining with two

spindles.

If the state where the speed of each spindle is within the range set with

parameter No.7631, and has lasted at least for the duration specified

with parameter No.7632, the spindle polygon speed arrival signal

PSAR <F0063#2> is set to 1.

Multiplier influencing the slave spindle speed

7635

[Data type] Byte

[Unit of data] Slave spindle (min

-1

)/master spindle (min

-1

)

[Valid data range] 1 to 9

Set up a multiplier that will act on the distance through which the

slave spindle is to move.

In speed ratio control, the relationship between the speeds of the

spindles is:

Slave spindle speed = Master spindle speed ×

Setting of parameter No.

7635

NOTE

1 This parameter is used to set the slave spindle

speed to a multiple of the master spindle speed

when the spindle synchronous control function is

used.

2 This parameter is irrelevant to the polygon turning

function and the polygon machining function with

two spindles.

3 The spindle synchronous control option is needed.

4 Bit 2 (SBR) of parameter No. 7603 and parameter

No. 7636 also need be set up.
