4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 346 -

4.26.2 Parameters of Threading Cycle

Chamfering distance in the threading cycles G76 and G92

5130

[Data type] Byte

[Unit of data] 0.1 pitch

[Valid data range] 0 to 127

This parameter sets the chamfering in the threading cycles G76 and

G92.

Chamfering angle in threading cycle

5131

[Data type] Byte

[Unit of data] degree

[Valid data range] 1 to 89

Set a chamfering angle in a threading cycle.

4.26.3 Parameters of Multiple Repetitive Canned Cycle

Depth of cut in multiple repetitive canned cycles G71 and G72

5132

[Data type] 2-word

[Unit of data]

Input increment IS-B IS-C Unit

Metric input 0.001 0.001 mm

Inch input 0.0001 0.0001 inch

[Valid data range] 0 to 99999999

This parameter sets the depth of cut in multiple repetitive canned

cycles G71 and G72.

Escape in multiple repetitive canned cycles G71 and G72.

5133

[Data type] 2-word

[Unit of data]

Input increment IS-B IS-C Unit

Metric input 0.001 0.001 mm

Inch input 0.0001 0.0001 inch

[Valid data range] 0 to 99999999

This parameter sets the escape in multiple repetitive canned cycle G71

and G72.
