4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 188 -

4.19 PARAMETERS OF DI/DO

#7 #6 #5 #4 #3 #2 #1 #0

MHI ZPO RWM

3001

MHI RWM

[Data type] Bit

RWM RWD signal indicating that rewinding is in progress

0 : Output only when the tape reader is being rewound by the reset

and rewind signal RRW

1 : Output when the tape reader is being rewound or a program in

memory is being rewound by the reset and rewind signal RRW

ZPO The reference position return completion signal for G28 or G30 is:

0 : Output upon completion of reference position return operation.

1 : Output at the time of positioning at the reference position after

completion of reference position return operation.

NOTE

Even if a reference position return operation is

performed in the machine lock state when this

parameter is set to 0, the reference position return

completion signal is output as the result of

execution of G28 or G30.

MHI Exchange of strobe and completion signals for the M, S, T, and B

codes

0 : Normal

1 : High-speed

#7 #6 #5 #4 #3 #2 #1 #0

3002 IOV

[Data type] Bit

IOV For the feedrate override signal, second feedrate override signal, and

rapid traverse override signal:

0 : Negative logic is used.

1 : Positive logic is used.

#7 #6 #5 #4 #3 #2 #1 #0

MVG MVX DEC DAU DIT ITX ITL

3003

MVX DEC DIT ITX ITL

[Data type] Bit

ITL Interlock signal for all axes

0 : Enabled

1 : Disabled

ITX Interlock signals for each axis

0 : Enabled

1 : Disabled
