4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 672 -

13618

Ratio of jerk rate change time in smooth bell-shaped

acceleration/deceleration before interpolation when AI contour control/AI

nano contour control is used (precision level 1)

13619

Ratio of jerk rate change time in smooth bell-shaped

acceleration/deceleration before interpolation when AI contour control/AI

nano contour control is used (precision level 10)

[Data type] Byte

[Unit of data] %

[Valid data range] 0 to 50

Each of these parameters sets the ratio of jerk rate change time to

acceleration rate change time in smooth bell-shaped

acceleration/deceleration before interpolation when AI contour

control/AI nano contour control is used.

Set a value (precision level 1) with emphasis placed on speed, and a

value (precision level 10) with emphasis on precision.

NOTE

When 0 or a value not within the valid data range is

set in these parameters, smooth bell-shaped

acceleration/deceleration before look-ahead

interpolation is not performed.

13620

Allowable acceleration rate when AI contour control / AI nano contour

control is used (precision level 1)

13621

Allowable acceleration rate when AI contour control / AI nano contour

control is used (precision level 10)

[Data type] 2-word axis

[Unit of data]

Increment system Unit

Metric machine 0.001mm/sec

[Valid data range] 0 to 99999999

These parameters set an allowable acceleration rate in the case of

emphasis on speed (precision level 1) and in the case of emphasis on

precision (precision level 10) when AI contour control/AI nano

contour control is used.
