4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 758 -

19743

Upper limit of the movement range of the second rotary axis

19744

Lower limit of the movement range of the second rotary axis

[Data type] 2-word

[Unit of data]

Increment system IS-B IS-C Unit

Metric machine 0.001 0.0001 mm

Inch machine 0.0001 0.00001 inch

[Valid data range] -99999999 to 99999999

In tool center point control for 5-axis machining (type 2), set the upper

limit and lower limit of the movement range of the second rotary axis.

When the movement range of the second rotary axis is not specified,

parameters No. 19743 and No. 19744 must both be set to 0.

19745

Limit of the deviation from the path

[Data type] 2-word

[Unit of data]

Increment system IS-B IS-C Unit

Metric machine 0.001 0.0001 mm

Inch machine 0.0001 0.00001 inch

[Valid data range] -99999999 to 99999999

Set an allowable path deviation limit when tool center point control

for 5-axis machining is used. When a path deviation is about to exceed

the limit set in this parameter if a movement is made at the specified

speed, the speed is automatically reduced so that the path deviation

does not exceed the limit. If 0 is set in this parameter, the least input

increment is used as an allowable path deviation limit. This parameter

is valid when bit 7 (SUP) of parameter No. 19696 is set to 1.

#7 #6 #5 #4 #3 #2 #1 #0

19746 CRS SAC

[Data type] Bit

SAC Rotary axis angle checking at the start of the tool center point control

mode for 5-axis machining is:

0 : Disabled.

1 : Enabled.
