Series 16i/160i/160is/18i/180i/180is - Model B Parameter manual Page 427

Parameter manual
B-63530EN/03 4.DESCRIPTION OF PARAMETERS
- 415 -
#7 #6 #5 #4 #3 #2 #1 #0
SQC
6005
ADR SQC
NOTE
When at least one of these parameters is set, the
power must be turned off before operation is
continued.
[Data type] Bit
SQC Calling a subprogram with its sequence number by the subprogram
call function is:
0 : Disabled.
1 : Enabled.
ADR Calling a subprogram with address E by the subprogram call function
using a custom macro and macro executor special code is:
0 : Disabled.
1 : Enabled.
Address E can be set for parameters Nos. 6090 and 6091.
#7 #6 #5 #4 #3 #2 #1 #0
MLG
6006
MMG MLG
[Data type] Bit
MLG In conditional decision statements in custom macros, logical
operations:
0 : Cannot be used.
1 : Can be used.
MMG The system variables (#4001 to #4022) for reading modal information
can read:
0 : Modal information specified in up to the immediately preceding
block.
1 : Modal information specified in the block currently being
executed.
