4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 466 -

6811 Tool life count restart M code

[Data type] 2-word

[Valid data range] 0 to 255 (not including 01, 02, 30, 98, and 99)

When 0 is specified, it is ignored.

• For tool life management:

1 When the life is specified by the number of times, the tool

exchange signal is output when a tool life count restart M

code is specified if tool life of at least one tool group is

expired. A tool in life is selected in the specified group

when a T code command (tool life management group

command) is specified after the tool life count restart M

code is specified. A tool life counter is then incremented by

one.

2 When the life is specified by time, a tool in life is selected

in the specified group when a T code command (tool life

management group command) is specified after the tool life

count restart M code is specified.

• For the tool management function:

When a tool life count restart M code is specified, the counting

of the life of the tool attached to the spindle position is started.

1 When the life is counted by the number of times, the life

count target is switched to the tool attached to the spindle

position, and the life count is incremented by 1.

2 When the life is counted by time, only an operation for

switching the life count target to the tool attached to the

spindle position is performed.

When the tool attached to the spindle position is not a tool life

management target, no operation is performed.

6844

Remaining tool life (use count)

[Data type] Word

[Unit of data] Count

[Valid data range] 0 to 9999

This parameter sets a remaining tool life (use count) used to output the

tool life arrival notice signal TLCHB <F064#3> when the tool life is

specified as a use count.

NOTE

1 When the remaining life (use count) of a selected

tool reaches the value specified with this

parameter, tool life arrival notice signal TLCHB is

output to the PMC.

2 If a value greater than the life of a tool is specified

with this parameter, the tool life arrival notice signal

TLCHB is not output.
