Series 16i/160i/160is/18i/180i/180is - Model B Parameter manual Page 326

Parameter manual

Page of 782

/ 782

4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 314 -

Servo loop gain multiplier of the spindle for gear 1

4971

Servo loop gain multiplier of the spindle for gear 2

4972

Servo loop gain multiplier of the spindle for gear 3

4973

Servo loop gain multiplier of the spindle for gear 4

4974

[Data type] Word

Set the servo loop gain multipliers of the spindle for gears 1 to 4.

The multipliers are used to convert the amount of the position

deviation to the voltage used in the velocity command. Assign the data

obtained from the following equation to the parameters.

Loop gain multiplier = 2048000 × E × A/L

where;

E : Voltage required to rotate the spindle motor at 1000 min

-1

in the

velocity command

L : Rotation angle of the spindle per one motor rotation (normally

360)

A : Unit used for the detection (degree)

[Example] Let E be 2.2 V, L be 360 degrees, and A be 0.088 degrees/pulse.

Loop gain multiplier = 2048000 × 2.2 × 0.088/360 = 1101

* When the voltage specified for the spindle motor is 10 V at a

spindle speed of 4500 min

-1

, E is regarded as 2.2 V.

NOTE

The above parameters No.4970 to No.4974 are for

analog spindles.
