B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 379 -

5350

Positional deviation limit imposed during tapping axis movement in rigid

tapping using the second spindle

[Data type] 2-word

[Unit of data] Detection unit

[Valid data range] 1 to 99999999

This parameter sets a positional deviation limit imposed during

tapping axis movement in rigid tapping using the second spindle.

NOTE

This parameter is enabled when bit 1 (SPR) of

parameter No. 5204 is set to 1.

5351

Positional deviation limit imposed during spindle movement in rigid tapping

using the second spindle

[Data type] Word

[Unit of data] Detection unit

[Valid data range] 1 to 32767

This parameter is used to set a positional deviation limit imposed

during spindle movement in rigid tapping using the second spindle.

NOTE

This parameter is enabled when bit 1 (SPR) of

parameter No. 5204 is set to 1.

5352

Positional deviation limit imposed while the tapping axis is stopped in rigid

tapping using the second spindle

[Data type] Word

[Unit of data] Detection unit

[Valid data range] 1 to 32767

This parameter is used to set a positional deviation limit imposed

while the tapping axis is stopped in rigid tapping using the second

spindle.

NOTE

This parameter is enabled when bit 1 (SPR) of

parameter No. 5204 is set to 1.
