Series 16i/160i/160is/18i/180i/180is - Model B Parameter manual Page 46

Parameter manual
4.DESCRIPTION OF PARAMETERS B-63530EN/03
- 34 -
4.6 PARAMETERS OF DNC1 INTERFACE #2
#7 #6 #5 #4 #3 #2 #1 #0
0231 NFD ASI SB2
NOTE
When at least one of these parameters is set, the
power must be turned off before operation is
continued.
[Data type] Bit
SB2 Number of stop bits
0 : 1 bit
1 : 2 bits
ASI Data input code
0 : IEA or ISO (automatic recognition)
1 : ASCII Code
NFD When data is out, feed holes are
0 : Output before and after data section
1 : Not output
0233 Baud rate (DNC1 interface #2)
NOTE
When this parameter is set, the power must be
turned off before operation is continued.
[Data type] Byte
[Valid data range] 1 to 15
Specify a baud rate.
Set value Baud rate (bps) Set value Baud rate (bps)
1 50 9 2400
2 100 10 4800
3 110 11 9600
4 150 12 19200
5 200 13 38400
6 300 14 76800
7 600 15 86400
8 1200
