4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 212 -

Axis name (absolute coordinate) for current position display

3132

Axis name (relative coordinate) for current position display

3133

[Data type] Byte axis

[Valid data range] 0 to 255

These parameters set the axis name for current position display.

When G code system B or C is used, the axis name set in parameter

No.3132 is used for both absolute and relative coordinate axes.

The values set in these parameters are used only for display.

For a command address, the axis name set in parameter No.1020 is

used.

When 0 is specified in these parameters, the value set in parameter

No.1020 is used.

3134

Axis display order on workpiece coordinate system screen and workpiece

shift screen

[Data type] Byte axis

[Valid data range] 0, 1 to the number of controlled axes

This parameter specifies the order in which axes are displayed on the

workpiece coordinate system screen and workpiece shift screen (for T

series).

When the parameters of all axes are set to 0, all axes are displayed.

When the parameters of some axes are set, the axes for which a value

of 0 is specified do not appear. The displayed axes are consecutive

without spaces being left for non-displayed axes.
