B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 177 -

1943 Safe machine position of each axis (+ direction)

1944 Safe machine position of each axis (- direction)

13831 Safe machine position 1 of each axis (+ direction)

13832 Safe machine position 1 of each axis (- direction)

13833 Safe machine position 2 of each axis (+ direction)

13834 Safe machine position 2 of each axis (- direction)

13835 Safe machine position 3 of each axis (+ direction)

13836 Safe machine position 3 of each axis (- direction)

13837 Safe machine position 4 of each axis (+ direction)

13838 Safe machine position 4 of each axis (- direction)

[Data type] 2-word axis

[Unit of data, valid data range]

Input increment IS-A IS-B IS-C Unit

Metric input 0.01 0.001 0.0001 mm

Inch input 0.001 0.0001 0.00001 inch

Set a safe machine position for each axis.

The CNC and monitor always check the machine position on each

linear axis in the dual check safety function.

In safety signal mode B (state in which a guard open request is input,

and the guard is closed), if there is at least one linear axis whose

machine position is not in the safe machine position, the guard unlock

signal (*LGD) is set to 0 to disable guard unlocking. The state in

which the machine positions of all linear axes are within the safe

machine positions is one condition for setting the guard unlock signal

(*LGD) to 1 (to enable guard unlocking). If the machine position on a

linear axis exceeds the safe machine position in safety signal mode C

(state in which a guard open request is input and the guard is open), a

servo alarm No.477 or No.495 is issued.

Up to four safe machine positions can be set. Which safe machine

positions to choose depends on the safety speed/safety position

selection signal (safety input signal).

Safe machine position 1 assumes the value of parameter No. 1943 (No.

1944) if parameter No. 1943 (No. 1944) is not set to 0. Safe machine

position 1 assumes the value of parameter No. 13831 (13832) if

parameter No. 1943 (No. 1944) is set to 0.







≠

0) 1943 (No. 13831 No.Parameter

0) 1943 (No. 1943 No.Parameter

direction) ( 1position machine Safe







≠

0) 1944 (No. 13832 No.Parameter

0) 1944 (No. 1944 No.Parameter

direction) (- 1position machine Safe
