4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 94 -

1442 Maximum allowable manual handle feedrate 2 for each axis

[Data type] Word axis

[Unit of data, valid data range]

Valid data range

Input increment Unit of data

IS-A, IS-B IS-C

Metric machine 1 mm/min 6 to 15000 6 to 12000

Inch machine 0.1 inch/min 6 to 6000 6 to 4800

Rotary axis 1 deg/min 6 to 15000 6 to 12000

Set a maximum allowable manual handle feedrate for each axis.

1443 External deceleration rate 3 of cutting feed

[Data type] Word

[Unit of data, valid data range]

Valid data range

Input increment Unit of data

IS-A, IS-B IS-C

Metric machine 1 mm/min 6 to 15000 6 to 12000

Inch machine 0.1 inch/min 6 to 6000 6 to 4800

Set the external deceleration rate of cutting feed.

1444 External deceleration rate 3 of rapid traverse for each axis

[Data type] Word axis

[Unit of data, valid data range]

Valid data range

Input increment Unit of data

IS-A, IS-B IS-C

Metric machine 1 mm/min 6 to 15000 6 to 12000

Inch machine 0.1 inch/min 6 to 6000 6 to 4800

Rotary axis 1 deg/min 6 to 15000 6 to 12000

Set the external deceleration rate of rapid traverse for each axis.

1445 Maximum allowable manual handle feedrate 3 for each axis

[Data type] Word axis

[Unit of data, valid data range]

Valid data range

Input increment Unit of data

IS-A, IS-B IS-C

Metric machine 1 mm/min 6 to 15000 6 to 12000

Inch machine 0.1 inch/min 6 to 6000 6 to 4800

Rotary axis 1 deg/min 6 to 15000 6 to 12000

Set a maximum allowable manual handle feedrate for each axis.
