4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 96 -

1451

Feedrate for one-digit F code feed command F1

1452

Feedrate for one-digit F code feed command F2

1453

Feedrate for one-digit F code feed command F3

1454

Feedrate for one-digit F code feed command F4

1455

Feedrate for one-digit F code feed command F5

1456

Feedrate for one-digit F code feed command F6

1457

Feedrate for one-digit F code feed command F7

1458

Feedrate for one-digit F code feed command F8

1459

Feedrate for one-digit F code feed command F9

These parameters can also be set on the “Setting screen”.

[Data type] 2-word

[Unit of data, valid data range]

(1) When the F1U parameter (bit 0 of parameter No.1405) is 0

Valid data range

Input increment Unit of data

IS-A, IS-B IS-C

Metric machine 0.1 mm/min 6 to 150000 6 to 120000

Inch machine 0.01 inch/min 6 to 60000 6 to 48000

Rotary axis 0.1 deg/min 6 to 150000 6 to 120000

(2) When the F1U parameter (bit 0 of parameter No.1405) is 1

Valid data range

Input increment Unit of data

IS-A, IS-B IS-C

Metric machine 1 mm/min 6 to 15000 6 to 12000

Inch machine 0.1 inch/min 6 to 6000 6 to 4800

Rotary axis 1 deg/min 6 to 15000 6 to 12000

These parameters set the feedrates for one-digit F code feed

commands F1 to F9. When a one-digit F code feed command is

specified, and the feedrate is changed by turning the manual pulse

generator, the parameter-set value also changes accordingly.
