4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 502 -

7522 Retract amount

[Data type] 2-word axis

[Unit of data]

Input increment IS-A IS-B IS-C Unit

Linear axis (input in mm) 0.01 0.001 0.0001 mm

Linear axis (input in inches) 0.001 0.0001 0.00001 inch

Rotary axis 0.01 0.001 0.0001 deg

[Valid data range] -99999999 to 99999999

This parameter sets the amount of travel by retract operation during

high-speed remote buffer operation for each axis.

7523 Retract feedrate

[Data type] 2-word axis

[Unit of data, valid data range]

Valid data range

Input increment Units of data

IS-A, IS-B IS-C

Metric machine 1 mm/min 30 to 240000 6 to 100000

Inch machine 0.1 inch/min 30 to 96000 6 to 48000

Rotary axis 1 deg/min 30 to 240000 6 to 100000

This parameter sets the traverse feedrate in retract operation during

high-speed remote buffer operation for each axis.

NOTE

The sum of the feedrate in high-speed remote buffer

operation and that set in this parameter is limited

according to the interpolation period. If the

maximum feedrate listed in the following table is

exceeded, P/S alarm No. 179 is issued.

Valid data range Input

increment

Unit of

data

Interpolated

time

IS-A, IS-B IS-C

16,8,4 msec 490000 49000

2 msec 980000 98000

1 msec 1960000 196000

Metric machine 1 mm/min

0.5 msec 3920000 392000

16,8,4 msec 190000 19000

2 msec 380000 38000

1 msec 760000 76000

Inch machine

0.1

inch/min

0.5 msec 1530000 153000

16,8,4 msec 490000 49000

2 msec 980000 98000

1 msec 1960000 196000

Rotary axis 1 deg/min

0.5 msec 3920000 392000
