B-63530EN/03 4.DESCRIPTION OF PARAMETERS

- 311 -

ESI Selection of a spindle positioning specification

0 : The conventional specification is used.

1 : The extended specification is used.

NOTE

The extended specification includes the following

two extensions:

(1) With the conventional specification, the number

of M codes for specifying a spindle positioning

angle is always 6. With the extended

specification, an arbitrary number of such M

codes from 1 to 255 can be selected by

parameter setting (See parameter No.4964.)

(2) The maximum feedrate for spindle positioning

(setting of parameter No.1420) can be

extended from 240000 to 269000 (in

increments of 10 deg/min).

IMB When the spindle positioning function is used, half-fixed angle

positioning based on M codes uses:

0 : Specification A

1 : Specification B

NOTE

In the case of half-fixed angle positioning based on M

codes, three types of spindle positioning operations

can occur:

(1) The spindle rotation mode is cleared, then the

mode is switched to the spindle positioning mode.

(2) Spindle positioning is performed in the spindle

positioning mode.

(3) The spindle positioning mode is cleared, then the

mode is switched to the spindle rotation mode.

In the case of specification A:

Operations (1) to (3) are specified using separate M

codes.

(1) Specified using M codes for performing spindle

orientation. (See parameter No.4960)

(2) Specified using M codes for specifying a spindle

positioning angle. (See parameter No.4962)

(3) Specified using M codes for clearing spindle

positioning operation. (See parameter No.4961.)

In the case of specification B:

When M codes for specifying a spindle positioning

angle are specified, operations (1) to (3) are

performed successively. (See parameter No.4962.)
