4.DESCRIPTION OF PARAMETERS B-63530EN/03

- 58 -

4.13 PARAMETERS OF COORDINATES

#7 #6 #5 #4 #3 #2 #1 #0

WZR AWK FPC ZCL ZPI ZPR

1201

AWK FPC ZCL ZPI ZPR

[Data type] Bit

ZPR Automatic setting of a coordinate system when the manual reference

position return is performed

0 : Not set automatically

1 : Set automatically

NOTE

1 ZPR is valid while a workpiece coordinate system

function is not provided. If a workpiece coordinate

system function is provided, making a manual

reference position return always causes the

workpiece coordinate system to be established on

the basis of the workpiece origin offset (parameters

No. 1220 to No. 1226), irrespective of this

parameter setting.

2 If an absolute-position detector is used in a system

not using a workpiece coordinate system function,

set this parameter.

ZPI Coordinates at the reference position when a coordinate system is set

automatically

0 : Value set in parameter No.1250 is used.

1 : For input in mm, the value set in parameter 1250 is used, or for

input in inches, the value set in parameter No.1251 is used.

This bit is ineffective, when a workpiece coordinate system option is

provided, however.

ZCL Local coordinate system when the manual reference position return is

performed

0 : The local coordinate system is not canceled.

1 : The local coordinate system is canceled.

FPC When the floating reference position is specified using soft keys on

the current position display screen

0 : The value of the displayed relative position is not preset. (In

other words, the value does not change.)

1 : The value of the displayed relative position is preset to 0.

AWK When the workpiece origin offset value is changed

0 : The absolute position display changed when the next buffering

block is performed.

1 : The absolute position display is changed immediately. (Only

when automatic operation is not activated)

Changed value is valid after buffering the next block.
